T series Hydraulic Bottle Jack from TITANSUHE is the economic model with good quality and very competitive prices. It is also our most selling model. Featured with robust construction, rugged base,glide-action pump, and high-quality oil and oil-by-pass, this bottle jack provides reliable and durable service. It is widely used for car repair and maintenance.
Model | Capacity | Min. H | Raising H. | Adjust H. | N.W. | Qty/Ctn | Meas. | 20'FCL |
(Ton) | (mm) | (mm) | (mm) | (kg) | (pcs) | (cm) | (pcs) | |
T0202 | 2 | 148 | 80 | 50 | 2.1 | 10 | 51x24x19 | 7300 |
T0202B | 2 | 148 | 80 | 50 | 2.1 | 10 | 51x24x19 | 7300 |
T0402 | 3 or 4 | 175 | 100 | 50 | 2.8 | 5 | 58x13x21 | 5300 |
T0402B | 3 or 4 | 175 | 100 | 50 | 2.8 | 5 | 58x13x21 | 5300 |
T0602 | 5 or 6 | 185 | 110 | 60 | 3.8 | 5 | 63x14x23 | 3920 |
T0602B | 5 or 6 | 185 | 110 | 60 | 3.8 | 5 | 63x14x23 | 3920 |
T0802 | 8 | 200 | 125 | 60 | 3.8 | 4 | 28x28x23 | 3140 |
T1002 | 10 | 200 | 125 | 60 | 4.6 | 2 | 30x15x23 | 2790 |
T1202 | 12 | 210 | 130 | 60 | 5.2 | 2 | 32x16x24 | 2340 |
T1602 | 15 or 16 | 225 | 140 | 60 | 6 | 2 | 33x17x26 | 1956 |
T2002 | 20 | 235 | 145 | 60 | 7.2 | 2 | 37x18x27 | 1530 |
T3202 | 30 or 32 | 255 | 150 | - | 12 | 2 | 38x20x31 | 970 |
T5002 | 50 | 255 | 155 | - | 18.5 | 1 | 22x21x32 | 765 |
T7002 | 70 | 300 | 180 | - | 39 | 1 | 25x20x31 | 550 |
T10002 | 100 | 335 | 180 | - | 70 | 1 | 54x44x35 | 230 |
