Our factory aiming to integrate German advanced elevator technology, rigorous production technology, and scientific management concepts into the Chinese elevator industry, and inject strong impetus into the development of Chinese cities, as a professional elevator solution supplier.
Realizing stability and comfort
Employing freight elevator's exclusive WVF technology to reduce the vibration and shaking during the movement of the elevator, achieving stable and comfortable experience for the passengers.
Professional Car
Freight elevators have double solid sedan at the end of reliable withstand all kinds of goods, precision weighing switch to strictly control the load in order to prevent overloading of accidents. On the ground with non-slip tread plate, so that grease pollution also can generate enough friction to prevent persons slipping or cargo slide.
Best cargo transport tool
It becomes your most competent assistant because of its exceptionally long service life, effective and energy-saving operation and loading, steady and reliable performance. In addition, it is finest goods transport tool.
High effect elevator vector inverter
Application of high-performance current vector control and absolute encoders, high-performance sensorless torque compensation function which make the elevator ride more comfortable, elevator traction machine can be stopped based learning, more simple and convenient elevator maintenance; automatic transfer torque boost function can easily cope with a variety of load lift.
Large width door opening, free entry/exit
For the convenience of free entry/exit of large bulk freight, Schmidt freight elevator series apply multi-folded car structures. It can reach maximum width while opening the car door.
The multiple door opening modes
In order to satisfy different entry/exit requirements from vast users, the Schmidt freight elevator offers four-door opening modes of side opening，center opening double-folded door, one-way door opening, opposite door opening. It can flexibly match with the factory, warehouse, department store, shopping center, housing property management center etc.
Freight elevators apply micro-computer computer control technology. It uses high intensity cars that have been designed and manufactured by section materials. It can transport the freight under various awful conditions. Schmidt freight elevator is your ideal choice in the factory, warehouse, department store, shopping center, housing property management center etc. because of its safe; durable and reliable properties, high structural strength, smooth operation, large door opening distance, high cost performance and so on.
Function name | Function elucidation |
VVVF drive | Motor rotating speed can be precisely adjusted to got smooth speed curve in lift start, travel and stop and gain the sound comfort. |
VVVF door operator | Motor rotating speed can be precisely adjusted to get the more gentle and sensitive door machine start/stop. |
Independent running | The lift can not respond to outer allying. but only respond to the command inside the car through the action switch. |
Automatic pass without stop | When the car is crowded with the passengers or the load is close to preset value, the car will automatically pass the calling landing in order to |
keep maximum travel efficiency. | |
Automatically adjust door | Door open time can be automatically adjusted according to the difference between landing calling or car calling. |
opening time | |
Reopen with hall call | In the door shutting process, press reopen with hall call button can restart the door. |
Express door closing | When the lift stops and opens the door. Press door-shut button. the door will be closed immediately. |
Car stops and door open | The lift decelerates and levels, the door only opens after the lift comes to a complete stop. |
Car arrival gong | Arrival tong in the car top announces that the passengers arrive. |
Command register cancel | If you press the wrong floor command button in tho car, twice continuous pressing of same button can cancel the registered command. |
Photocell protection | In the door open and shut period, infrared light that covers the whole door height is used to probe the door protection device of both the |
passengers and objects. | |
Designated stop | If the Iift can not open the door in the destination floor out of some reason, the lift will close the door and travel to the next designated floor. |
Overload holding stop | When the car is overload. the buzzer rings and stops the lift in the same floor. |
Start protection control | If the Iift does not leave door zone within the designated time after it gets started. it will stop the operation. |
Inspection operation | When the lift enters into inspection operation, the car travels at inching running. |
Fault self-diagnosis | The controller can record 62 latest troubles so as to quickly remove the trouble and restore the lift operation |
Repeated door closing | If the lift can not close the door due to certain obstacle or interference, the lift will reopen or re-shut the door until sundries are eliminated. |
Up/down overrun and final | The device can effectively prevent from the lift's surging to the top or knocking the bottom when it is out of the control. It results in the more safe |
limit protection | and reliable lift travel. |
Down over-speed protection device | When the lift downs 1.2 times higher than the rated speed, this device will automatically cut off control mains, stop the motor running so as to |
stop lift down at over peed. If the lift continues to down at over speed, and the speed is 1.4 times higher than rated speed, safety tongs act to | |
force the lift stop in order to ensure the safety. | |
Upward over-speed protection device | When the Iift ups 1.2 times higher than rated speed. the device will automatically decelerate or brake the lit. |
Micro-touch button for car call and hall call | Novel micro-touch button is used for operation panel command button in the car and landing calling button. |
Floor and direction indicator inside car | The car shows the lit floor location and current travel direction. |
Floor and direction indicator in hall | The landing shows the lift floor location and current travel direction. |
Emergency car lighting | Emergency car lighting automatically activated once power failure. |
Five way intercom | Communication amid car, car top, lift machine room, well pit and rescue duty room through walkie-talkie. |
Bell | In emergency conditions, if bell button above car operation panel is continuously pressed, electric bell rings on top of the car. |
Fire emergence return | If you start key switch in main landing or monitor screen, all the callings will be canceled. The Iift directly and immediately drives to the designated |
rescue landing and automatically opens the door. | |
Car ventilation, light automatic shut off | If there is no allying or command signal within the stipulated time. the car fan and lighting will be automatically closed in order to save the energy. |
Remote shut-off | The lift can be called to main landing (after finishing the service) through the key switch and automatically exists the service. |
