Name: Hydraulic Wire Rope Pressing Machine
Brand: CHONGQING TITAN SUHE TECH CO., LTD.
Price: 25 USD
Rating: 4.5 (5 reviews)

Hydraulic Wire Rope Pressing Machine

The main power of sleeve pressing machine is a hydraulic system. It has outstanding features of compact structure, stable operation, low noise and high work efficiency. The steel wire rope slings inserted by the press sleeve machine present no offset and can be done in 3 seconds of one set. Compared with hand-knitted wire rope sling, it takes almost 15 minutes by a 5-year-old master to produce a set, they two methods have a hundred times difference in efficiency.

The wire rope pressing machine are customized products, price is determined by the sizes.

Features of Hydraulic Wire Rope Pressing Machine

A dual hydraulic system which combines the use of high speed and low pressure to bring dies into position. And the low speed and high pressure necessary for ideal swaging control
Adjustable tonnage control, so tonnage can be set to match die block working load limit.
Four column wide stance which provides the operator working clearance between columns a large area for in-process sling storage.
Vertical swage action which gives an equalized press on the fitting to produce uniform high quality
Self locating spring locks snap the shoe-type dies into place for quick set-up and change
The voltage and frequency can be designed and produced as per customer’s need.
Dies sizes according to customer's request

Attention for use

There must be no oil in the fuel tank when the machine is being lifted.
The input power of the machine must be 380V, 50Hz three-phase AC.
The grounding protection wire must be connected securely.
Mold must be installed well before starting the machine so to avoid accidents.
Oil must be injected from the air filter.
New machine should get all oil cleaned for the first time after it be used for one week. For cleaning frequency in next few months it depends on the working load, we recommend to replace the oil every 3-6 months aiming to prolong service life of the machine.
The pump and overflow valve have been debugged in the factory, user shouldn't adjust it randomly.
Do not place other hard objects on the cylinder thus can prevent the mold from being damaged when the piston goes down.
Cut off the power supply when replace the mold.

Data Sheet of Hydraulic Wire Rope Pressing Machine

MODEL	YSD-100	YSD-200	YSD-300	YSD-350	YSD-500	YSD-650	YSD-800	YSD-1000	YSD-1500	YSD-2000
SPECIFICATION	100T	200T	300T(320T)	350T	500T	650T	800T	1000T	1500T	2000T
MAX.FORCE(KN)	1000	2000	3200	3500	5000	6500	8000	10000	15000	20000
MAX.WORKING PRESSURE(MPA)	28	56	28	56	28	28	28	56	56	56
MAX.DIAMETER IN ONE PRESSING (MM)	14	20	26	28	32	36	42	46	54	64
MAX.DIAMETER IN MULTI-PRESSING (MM)	18	25	32	34	42	44	50	56	64	74
MAX.PISTON MOVEMENT (MM)	100	100	130	100	150	150	190	200	220	230
PISTON WORKING MOVEMENT (MM)	80	80	100	80	130	130	170	180	200	210
THE UP SPEED OF PISTON (MM/S)	6.8	8	4.8	5	4.5	4.4	3.6	4.5	4.5	3.6
THE DOWN SPEED OF PISTON (MM)	9.6	10	8.8	8	7.9	7.8	7.6	7.8	7.8	7.8
MOTOR POWER (KW)	3	2.2	4	3	5.5	7.5	7.5	5.5+4	7.5+4	11+4
NET WEIGHT（KG）	680	900	1500	1000	2700	3500	4600	7000	9000	13500
OVERALL DIMENSION (MM)	1000 x 500 x 960	1200 x 600 x 1400	1400 x 600 x 1600	1200 x 600 x 1400	1550 x 650 x 1700	1600 x 680 x 1880	1800 x 800 x 2100	2000 x 800 x 2100	2200 x 900 x 2180	2500 x 1200 x 2200

Titansuhe is dedicated to providing a full range of wire rope sling parts, we offer cost-effective and reliable solutions.
