1 inch Ratchet straps is designed and produced for cargo controls with light weight. The maximum breaking strength is 1000kg. It normally come in one piece with cam buckle or two pieces with ratchet buckle. The cam buckle straps are mainly used for luggage bundling which tightened by hand pulling the strap end. Ratchet strap belt is used to lashing and securing cargo on moving trolley or truck for easy transportation.
Width | W.L.L. | Min. Breaking Strength | Length (m) | ||
(mm/inch) | kg | lbs | kg | lbs | |
25 （1") | 125 | 250 | 250 | 550 | 3 |
25 （1") | 150 | 330 | 300 | 660 | 3 |
25 （1") | 200 | 440 | 400 | 880 | 3 |
Width | W.L.L. | Min. Breaking Strength | Length (m) | N.W. (kg) | Sets Per Carton | Dimension of Carton(cm) | |||
(mm/inch) | kg | lbs | kg | lbs | Fixed end | Loose end | |||
25 （1") | 150 | 330 | 450 | 990 | 0.5 | 2.5 | 0.38 | 90 | 49x30x29 |
25 （1") | 200 | 440 | 600 | 1320 | 0.5 | 2.5 | 0.4 | 85 | 49x30x29 |
25 （1") | 250 | 550 | 800 | 1650 | 0.5 | 2.5 | 0.42 | 80 | 49x30x29 |
25 （1") | 300 | 660 | 900 | 1980 | 0.5 | 2.5 | 0.43 | 75 | 49x30x29 |
25 （1") | 350 | 770 | 1000 | 2310 | 0.5 | 4 | 0.5 | 60 | 49x30x29 |
